Trinocular biological microscope designed for developing advanced microscopy techniques. Ideal for research, higher education and for diagnostic work in clinical laboratories.
Its trinocular head is adaptable to digital devices (not included) for image and video documentation. Its mechanical stage provides fine and smooth movement control, providing precise orientation, a useful feature during histology and cytology tests. The diopter adjustment (on one eyepiece) let you compensate for the differences between your own two eyes.
Product Specifications:
| EYEPIECES | PL 10X/18 mm with ± 5 mm diopter adjustment in one eyepiece. |
| HEAD | Trinocular Siedentopf type, 30° inclined with interpupillary distance adjustment between 50 – 75 mm / 1.96”- 2.95”. |
| NOSEPIECE | Quadruple nosepiece with anti-slip ring and click-stops, mounted on high-tension ball bearings. |
| OBJECTIVES | 4X, 10X, 40X (S) and 100X (S) (oil), achromatic optics and color ring for easy identification. |
| STAND | Stative, robust and reinforced with epoxy paint finish. |
| STAGE | Double plate with X-Y coaxial movement, 5.51” x 5.19”, vernier, millimeter scale (3.46” x 2.36”), clamp and height adjustment with stop. |
| CONDENSER | Abbe, N.A. 1.25, with height adjustment . |
|
DIAPHRAGM |
Iris with filter holder. |
| FOCUSING | Coarse and fine anti-slip control knob with 0.002 mm precision and tension adjustment. |
| ILUMINATION | 3W LED with intensity control. |
| POWER SUPPLY | 110-240V, 50/60 Hz, AC Adapter. |
Accessories included:
Accessories not included:
